Interrupteur TBS135A - alt, SPNO 5amp, faible force - longue distance
Description du produit
Air Switch / Pneumatic Switch- Manufactured by Techmark TBS135A - Single Pole, Single Throw...
This means this is a simple line conductor with a simple on/off configuration. 2 flat spade conductors are used to connect the circuit. This switch is an alternate action meaning it will hold in the on position and then hold in the off position when activated. Height: 48mm, Width: 28mm (at widest point) Depth: 48mm (from front to rear spade)
Up to 250vac. 5A resistive, 2A inductive. Specifically designed to run at low pressure. Fits hole size: 15mm
This switch is basically the same as the TBS106A but is designed to work at long distance i.e. over 3 metres. Atmospheric pressure can build up in long runs of pipe and cause the switch to come on of its own accord. With this switch it has a special release inside that stops this from happening. Basic operation is to switch either directly an appliance or a relay.
This means this is a simple line conductor with a simple on/off configuration. 2 flat spade conductors are used to connect the circuit. This switch is an alternate action meaning it will hold in the on position and then hold in the off position when activated. Height: 48mm, Width: 28mm (at widest point) Depth: 48mm (from front to rear spade)
Up to 250vac. 5A resistive, 2A inductive. Specifically designed to run at low pressure. Fits hole size: 15mm
This switch is basically the same as the TBS106A but is designed to work at long distance i.e. over 3 metres. Atmospheric pressure can build up in long runs of pipe and cause the switch to come on of its own accord. With this switch it has a special release inside that stops this from happening. Basic operation is to switch either directly an appliance or a relay.
Attributs du produit
Marque: Tecmark |
Type de produit: Interrupteur d’air |
Fonction: SPNO |
Attributs du produit
Marque: Tecmark |
Type de produit: Interrupteur d’air |
Fonction: SPNO |
Description du produit
Air Switch / Pneumatic Switch- Manufactured by Techmark TBS135A - Single Pole, Single Throw...
This means this is a simple line conductor with a simple on/off configuration. 2 flat spade conductors are used to connect the circuit. This switch is an alternate action meaning it will hold in the on position and then hold in the off position when activated. Height: 48mm, Width: 28mm (at widest point) Depth: 48mm (from front to rear spade)
Up to 250vac. 5A resistive, 2A inductive. Specifically designed to run at low pressure. Fits hole size: 15mm
This switch is basically the same as the TBS106A but is designed to work at long distance i.e. over 3 metres. Atmospheric pressure can build up in long runs of pipe and cause the switch to come on of its own accord. With this switch it has a special release inside that stops this from happening. Basic operation is to switch either directly an appliance or a relay.
This means this is a simple line conductor with a simple on/off configuration. 2 flat spade conductors are used to connect the circuit. This switch is an alternate action meaning it will hold in the on position and then hold in the off position when activated. Height: 48mm, Width: 28mm (at widest point) Depth: 48mm (from front to rear spade)
Up to 250vac. 5A resistive, 2A inductive. Specifically designed to run at low pressure. Fits hole size: 15mm
This switch is basically the same as the TBS106A but is designed to work at long distance i.e. over 3 metres. Atmospheric pressure can build up in long runs of pipe and cause the switch to come on of its own accord. With this switch it has a special release inside that stops this from happening. Basic operation is to switch either directly an appliance or a relay.
